Si341009 Model Names of Indoor / Outdoor Units
General Information 2
1. Model Names of Indoor / Outdoor Units
1.1 Indoor Units
Note: FXDQ has following 2 series, as shown below.
FXDQ-PBVET, NBVET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-PBVE, NBVE: with Drain Pump
* It is possible to keep R-22 indoor units from K-series and later version. Field setting to R-22 on the PCB is
necessary. For details, refer to the installation manual of RQYQ-P. It is not possible to combine old R-22
and new R-410A indoor units in one system due to incompatibility of communication.
RQYQ-P is not compatible to R-407C indoor units.
Connection unit series indoor units
Note: BEV unit is required for FXUQ only.
MA: RoHS Directive models; Specifications, dimensions and other functions are not changed
compared with M type.
Capacity range
0.8HP
1HP
1.25HP
1.6HP
2HP
2.5HP 3.2HP
4HP 5HP 6HP 8HP 10HP
Power
Supply
Capacity index 20 25 31.25 40 50 62.5 80 100 125 140 200 250
Ceiling Mounted
Cassette Type
(Round Flow)
FXFQ — 25P 32P 40P 50P 63P 80P 100P 125P — — —
VE
Ceiling Mounted
Cassette (Compact
Multi Flow) Type
FXZQ 20M 25M 32M 40M 50M — — — — — — —
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — — —
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25MA 32MA 40MA — 63MA — — — — — —
Slim Ceiling Mounted
Duct Type
FXDQ-
PBVE
20PB 25PB 32PB — — — — — — — — —
FXDQ-
PBVET
20PB 25PB 32PB — — — — — — — — —
FXDQ-
NBVE
— — — 40NB 50NB 63NB — — — — — —
FXDQ-
NBVET
— — — 40NB 50NB 63NB — — — — — —
Ceiling Mounted
Duct Type
(Middle and high
static pressure)
FXMQ 20P 25P 32P 40P 50P 63P 80P 100P 125P 140P — —
Ceiling Mounted
Duct Type
FXMQ——————————
200MA 250MA
Ceiling Suspended
Type
FXHQ — — 32MA — — 63MA —
100MA
————
Wall Mounted Type
FXAQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — — —
Floor Standing Type
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — — —
Concealed Floor
Standing Type
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA — — — — — —
Capacity range 3HP 4HP 5HP
Power
Supply
Capacity index 71 100 125
Ceiling Suspended
Cassette Type
FXUQ 71MA 100MA 125MA V1
Connection Unit for
FXUQ
BEVQ 71MA 100MA 125MA VE
