Specifications Si341009
11 Specifications
Note:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name RQYQ12PY1 RQYQ14PY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 29,000 34,600
Btu / h 115,000 137,000
kW 33.7 40.2
★2 Cooling Capacity (19.0°CWB)
kW
33.5 40.0
★3 Heating Capacity
kcal / h 32,300 38,700
Btu / h 128,000 154,000
kW 37.5 45.0
Casing Colour Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1680×930×765 1680×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Compressor
Displacement Volume
m³/h 13.34+10.53 13.34+10.53+10.53
Number of Revolutions r.p.m 6300, 2900 6300, 2900, 2900
Motor Output×Number
of Units
kW (3.3+4.5)×1 (1.6+4.5+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.35×2
Airflow Rate m³/min 200 233
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
12.7 (Brazing Connection)
φ
12.7 (Brazing Connection)
Gas Pipe mm
φ
28.6 (Brazing Connection)
φ
28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 284 381
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 14~100 10~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 11.7 11.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D069104A C: 4D069105A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
