Troubleshooting by Remote Controller Si341009
173 Troubleshooting
Power Transistor Check
CHECK 4
Perform the following procedures prior to check.
(1) Power Off.
(2) Remove all the wiring connected to the PCB where power transistors are mounted on.
[Preparation]
·
Tester
∗ Preparing a tester in the analog system is recommended.
A tester in the digital system with diode check function will
be usable.
[Point of Measurement and Judgement Criteria]
·
Measure the resistance value using a tester at each point of measurement below, 10 minutes later after power OFF.
To use analog tester:
Measurement in the resistance value mode in the range of
multiplying 1kΩ.
Point of Measurement
Judgement Criteria
Remarks
+–
No.
15kΩ and
above
(including )
2 ~ 15kΩ
2 ~ 15kΩ
Due to condenser charge
and so on, resistance
measurement may require
some time.
P2
P2
P2
U
V
W
N3
N3
N3
U
V
W
1
2
3
4
5
6
7
8
9
10
11
12
P2
P2
P2
U
V
W
U
V
W
N3
N3
N3
Point of Measurement
Judgement Criteria
Remarks
+–
No.
0.3 ~ 0.7V
1.2V and over
1.2V and over
Due to condenser charge
and so on, resistance
measurement may require
some time.
Due to condenser charge
and so on, resistance
measurement may require
some time.
P2
P2
P2
U
V
W
N3
N3
N3
U
V
W
1
2
3
4
5
6
7
8
9
10
11
12
P2
P2
P2
U
V
W
U
V
W
N3
N3
N3
To use digital tester:
Measurement is executed in the diode check mode. ( )
[PCB and Circuit Diagram]
