Detailed Control Functions Si341009
47 Function
2.5.5 STD Compressor Overload Protection
This control is used to prevent abnormal heating due to overcurrent to the compressor resulting
from failures of STD compressor such as locking.
STD compressor ON
CT detection current value>28.8A
STD compressor OFF for 30 min.
(2 times per 90 minutes at max.)
Stop due to malfunction
("E6" displayed)
Demand to operate.
