Field Setting from Outdoor Unit Si341009
61 Test Operation
(2) Service setting items
Setting item Content and objective of setting Overview of setting procedure
1
Indoor unit fan
forced H operation
Used to operate the indoor unit in the
stopped state in forced H operation mode.
Set No. 5 of "Setting mode 2" to indoor unit
forced fan H.
2
Indoor unit forced
operation
Used to operate the indoor unit in forced
operation mode.
Set No. 6 of "Setting mode 2" to indoor unit
forced operation mode.
3
Change of targeted
evaporation
temperature
(in cooling)
In cooling operation, used to change the
targeted evaporation temperature for
compressor capacity control.
Select high side or low side with No. 8 of
"Setting mode 2".
4
Change of targeted
condensing
temperature
(in heating)
In heating operation, used to change the
targeted condensing temperature for
compressor capacity control.
Select high side or low side with No. 9 of
"Setting mode 2".
5
Setting of defrost
selection
Used to change a temperature at which the
defrost operation is initiated, thus making the
initiation easy or hard.
Select fast side or slow side with No. 10 of
"Setting mode 2".
6
Setting of
sequential startup
Used to start units not in sequence but
simultaneously.
Set No. 11 of "Setting mode 2" to NONE.
7
Emergency
operation
If the compressor has a failure, used to
prohibit the operation of compressor(s)
concerned or outdoor unit(s) concerned and
to conduct emergency operation of the
system only with operable compressor(s) or
outdoor unit(s).
Make this setting while in "Setting mode 2".
For system with a single outdoor unit: Set with
No. 19 or 42.
For system with multiple outdoor units: Set with
No. 38 or 39.
8 Air tight test
Fully open the outdoor unit and indoor unit
expansion valves, and turn on some of the
solenoid valves.
Set No. 21 of "Setting mode 2" to ON.
9
Refrigerant
recovery mode
Used to recover refrigerant onsite.
With operations of indoor and outdoor units
prohibited, fully open the expansion valve of
the indoor and outdoor units.
Set No. 21 of "Setting mode 2" to ON.
10 Vacuuming mode
Used to conduct vacuuming onsite.
Fully open the expansion valves of the
indoor and outdoor units, and energize some
of solenoid valves. Use a vacuum pump to
conduct vacuuming.
Set No. 21 of "Setting mode 2" to ON.
11
Power transistor
check mode
Used for the troubleshooting of DC
compressors.
Inverter waveform output makes it possible
to judge whether a malfunction results from
the compressor or the PCB.
Set No. 28 of "Setting mode 2" to ON.
12
Setting of model
with spare PCB
In order to replace the PCB by a spare one,
be sure to make model setting.
For this setting, set the DS2-2, -3, and-4
switches on the PCB to the model concerned.
