Troubleshooting by Remote Controller Si341009
143 Troubleshooting
2.33 Power Supply Insufficient or Instantaneous Failure
Remote
Controller
Display
U2
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
Detection of voltage of main circuit capacitor built in the inverter PCB and power supply voltage.
Error Decision
Conditions
When the voltage aforementioned is not less than 190V.
Supposed
Causes
Power supply insufficient
Instantaneous power failure
Open phase
Defective inverter PCB
Defective outdoor control PCB
Defective compressor
Defective main circuit wiring
Defective fan motor
Defective connection of signal cable
