Troubleshooting by Remote Controller Si341009
115 Troubleshooting
2.15 High Pressure Switch System Abnormality
Remote
Controller
Display
H3
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
The protection device circuit checks continuity in the high pressure switch.
Error Decision
Conditions
When there is no continuity in the high pressure switch during the compressor stops operating.
Supposed
Causes
Defective high pressure switch
Broken of high pressure switch harness
Defective connection of high pressure switch connector
Defective compressor
Defective outdoor unit PCB
Broken of lead wire
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Wait for 10 minutes after unit
stops, then check the
following.
Is there
continuity at the lead wire?
Replace the sub PCB.
YES
NO
Replace the lead wire.
YES
Is the
protection HPS
connector (X32A) correctly
connected to the
outdoor unit
PCB?
NO
Connect it correctly.
YES
Is there
continuity at the control
and protection
HPS?
NO
Replace the HPS where there is
no continuity.
* If normal, the resistance will be
10Ω or less.
NO
Is there
a disconnection or
insulation failure at the
compressor
coil?
YES
Replace the compressor.
* If there is a compressor
malfunction, there is the
possibility that the INV. PCB and
outdoor unit PCB have been
damaged. Check that each of
these PCBs is normal.
