Si341009 Troubleshooting by Remote Controller
Troubleshooting 162
Troubleshooting
NO
YES
YES
YES
YES
NO
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Diagnosis Flow 3
Diagnosis Flow 4
Replace the outdoor unit main
PCB.
Check the model of the outdoor
unit.
Replace the spare PCB.
Check
if the unit is not
connected to outdoor
units of different
models.
Check
if the outdoor
unit PCB is replaced
with spare PCB.
Confirmation of error 3 Confirmation of error 4
Confirmation of error 3 Confirmation of error 4
NO
Is the setting of spare
PCB correct?
Correct the setting to reset the
power.
Replace the outdoor unit main PCB
(A1P).
NO
Multi-connection?
Replace the outdoor unit main
PCB.
