![Daikin RQYQ16PY1 [168/194] Improper combination of indoor and outdoor units indoor units and remote controller](/img/pdf.png)
Daikin RQYQ16PY1 [168/194] Improper combination of indoor and outdoor units indoor units and remote controller
![Daikin RQYQ18PY1 [168/194] Improper combination of indoor and outdoor units indoor units and remote controller](/views2/1718492/page168/bga8.png)
Troubleshooting by Remote Controller Si341009
159 Troubleshooting
2.40 Improper Combination of Indoor and Outdoor Units,
Indoor Units and Remote Controller
Remote
Controller
Display
UA
Applicable
Models
All indoor unit models
RQYQ8-48PY1
Method of Error
Detection
A difference occurs in data by the refrigerant type between indoor and outdoor units.
The number of indoor units is out of the allowable range.
Error Decision
Conditions
The error decision is made as soon as either of the abnormalities aforementioned is detected.
Supposed
Causes
Excess of connected indoor units
Defective outdoor unit PCB (A1P)
Mismatching of the refrigerant type of indoor and outdoor unit.
Setting of outdoor PCB was not conducted after replacing to spare PCB.
