Si341009 Troubleshooting by Remote Controller
Troubleshooting 130
2.25 Overcurrent Abnormal of Inverter Compressor
Remote
Controller
Display
L8
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
Error is detected from the current flowing in the power transistor.
Error Decision
Conditions
When the inverter secondary current value is below.
(1) 33.5A and over continues for 5 seconds.
(2) 27.6A and over continues for 260 seconds.
Supposed
Causes
Compressor overload
Compressor coil disconnected
Defective wiring to the compressor
Defective inverter PCB
