Si341009 Detailed Control Functions
Function 38
2.4 Normal Operation
2.4.1 List of Functions in Normal Operation
Part Name
Electric Symbol
Normal Cooling Normal Heating
RQYQ8P PQYQ10·12P PQYQ14·16P
Compressor
M1C M1C M1C
PI Control PI Control–M2CM2C
––M3C
Outdoor unit fan M1F M1F M1F, M2F
Depends on the
mode of the cooling
heat exchanger
Depends on the
mode of the cooling
heat exchanger
Four way valve Y3S Y3S Y3S OFF ON
Electronic expansion
valve (Main)
Y1E Y1E Y1E
2000 pls
Depends on the
control of the
electronic expansion
valve
Electronic expansion
valve (Main 2)
––Y2E
Electronic expansion
valve (Subcooling)
Y2E Y2E Y3E
Depends on the
control of the
electronic expansion
valve
0 pls
Solenoid valve (Hot
gas)
Y1S Y1S Y1S OFF OFF
Solenoid valve
(Receiver gas vent)
Y8S Y8S Y8S OFF OFF
Solenoid valve (Circuit
of oil return)
Y5S Y5S Y5S ON ON
Solenoid valve (Close
liquid pipe for stopped
outdoor unit)
Y6S Y6S Y6S OFF ON
Solenoid valve (Main
electronic expansion
valve bypass)
Y10S Y10S – ON OFF
Solenoid valve
(Refrigerant regulator
gas vent pipe)
Y11S Y11S Y10S OFF OFF
Solenoid valve
(Refrigerant regulator
liquid pipe)
Y12S Y12S Y11S OFF OFF
Solenoid valve
(Refrigerant regulator
gas pipe)
Y13S Y13S Y12S OFF OFF
Solenoid valve
(Refrigerant regulator
liquid outlet)
Y14S Y14S Y13S OFF OFF
Solenoid valve
(Receiver liquid level)
Y7S Y7S Y7S OFF OFF
Solenoid valve (Mixing
unit inlet)
Y4S Y4S Y4S OFF OFF
Solenoid valve (Bypass) Y2S Y2S Y2S OFF OFF
Solenoid valve (Oil
regulator outlet)
Y9S Y9S Y9S ON ON
Indoor unit fan M1F M1F M1F
Depends on the
indoor unit
Depends on the
indoor unit
Indoor unit electronic
expansion valve
Y1E Y1E Y1E
Depends on the
indoor unit
Depends on the
indoor unit
