![Daikin RQYQ12PY1 [12/194] Outdoor units](/views2/1718492/page12/bgc.png)
Model Names of Indoor / Outdoor Units Si341009
3 General Information
1.2 Outdoor Units
Y1: 3 phase, 380-415V, 50Hz
1.3 Air Treatment Equipment
Outdoor-air processing unit
HRV units (VKM series)
Note: For details, refer to Engineering Data ED71-613.
HRV units (VAM series)
VE: 1 phase, 220-240/220V, 50/60Hz
V1: 1 phase, 220-240V, 50Hz
Series Model Name Power Supply
Heat Pump RQYQ
8P 10P 12P 14P 16P 18P 20P 22P 24P
Y126P 28P 30P 32P 34P 36P 38P 40P 42P
44P 46P 48P
Series Model name Power supply
FXMQ 125MF 200MF 250MF V1
Series Model name Power supply
HRV units with DX
coil
VKM
50GA 80GA 100GA
V1
HRV units with DX
coil and humidifier
50GAM 80GAM 100GAM
Series Model name Power supply
HRV units VAM 150GJ 250GJ 350GJ 500GJ 650GJ 800GJ
1000GJ 1500GJ 2000GJ
VE
