Test Operation Si341009
59 Test Operation
1.3 Checking in Normal Operation
After check operation ends, start normal operation.
(Heating is not possible if the outdoor air temperature is 24°C or higher.)
• Check that the indoor and outdoor units are operating normally.
(If any abnormal noise occurs due to liquid compression in the compressor or another
cause, stop operation immediately. Then energize the crankcase heater for a sufficient
period of time before restarting operation.)
• Start the indoor units one by one. Verify that the corresponding outdoor unit is operating.
• Verify that cool air (or warm air) is being discharged by the indoor unit.
• Press the airflow direction button and airflow rate button of the indoor unit and verify their
operation.
<Important information when checking normal operation>
• If any abnormal noise occurs due to liquid compression in the compressor or another cause,
stop operation immediately. Then energize the crankcase heater for a sufficient period of
time before restarting operation.
• For approximately 5 minutes after the compressor is stopped, the compressor will not start
even when the ON/OFF buttons at indoor units in that system are pressed.
• Pump down residual operation may occur for up to 5 minutes at the outdoor unit after
operation was stopped from the remote controller.
• Outdoor unit fan low speed operation may also occur if the Night-time low noise setting or
the External low-noise setting is used.
• If check operation after installation was not performed by pressing the TEST button, or if the
check operation was not completed normally, error code "U3"
is displayed and normal
operation is not possible. Be sure to follow the instructions in "1-2. Check Operation" and
complete the check operation procedure.
