Si341009 Capacity Range
General Information 8
Indoor unit connection capacity
Type HP Capacity index Model name
Types of connected indoor units
Min. combination ratio
Standard indoor units
Max. combination ratio
Max. number of
connectable indoor
units
Single outdoor
units
8 200 RQYQ8PY1
50% 130%
13
10 250 RQYQ10PY1 16
12 300 RQYQ12PY1 19
14 350 RQYQ14PY1 22
16 400 RQYQ16PY1 26
Double
outdoor units
18 450 RQYQ18PY1 29
20 500 RQYQ20PY1 32
22 550 RQYQ22PY1 35
24 600 RQYQ24PY1 39
26 650 RQYQ26PY1 42
28 700 RQYQ28PY1 45
30 750 RQYQ30PY1 48
32 800 RQYQ32PY1 52
Triple outdoor
units
34 850 RQYQ34PY1 55
36 900 RQYQ36PY1 58
38 950 RQYQ38PY1 61
40 1,000 RQYQ40PY1
64
42 1,050 RQYQ42PY1
44 1,100 RQYQ44PY1
46 1,150 RQYQ46PY1
48 1,200 RQYQ48PY1
