Troubleshooting by Remote Controller Si341009
119 Troubleshooting
2.18 High Pressure Sensor Abnormality
Remote
Controller
Display
J1
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
Error is detected from the pressure measured with high pressure sensor.
Error Decision
Conditions
When the high pressure sensor is short-circuit or open circuit.
(Not less than 4.22MPa, or 0.01MPa or less)
Supposed
Causes
Defective high pressure sensor
Connection of low pressure sensor with wrong connection.
Defective outdoor unit PCB.
Defective connection of high pressure sensor
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
*1. Pressure sensor subject to error code
Error code
J1 High pressure sensor (Liquid pipe outlet) S2NPH
Electric symbolPressure sensor subject to malfunction code
Replace the outdoor unit sub PCB
(A2P).
Replace the high pressure sensor.
YES
NO
Replace the outdoor unit sub PCB
(A2P).
NO
Replace the high pressure sensor.
YES
NO
Are
the characteristics
of the high pressure sensor
normal? (Make a comparison
between the voltage characteristics
(*2) and the gauge
pressure.)
YES
If
the PCB
pressure detection normal?
(Make a comparison between the
checker pressure data and the
voltage characteristics
(*2).)
1.Set the high pressure gauge.
2.Connect the checker for
VRV.
Reset the operation, and then
restart the outdoor unit.
Are the
characteristics of the high
pressure sensor
normal?
