Si341009 Troubleshooting by Remote Controller
Troubleshooting 126
2.22 Inverter PCB Abnormality
Remote
Controller
Display
L1
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
Detect error by current value during waveform output before compressor startup.
Detect error by current sensor value during synchronized operation at the time of startup.
Error Decision
Conditions
When over-current is detected at the time of waveform output before operating the
compressor
When the current sensor error during synchronized operation
When overvoltage occurs in IPM
Supposed
Causes
Defective outdoor unit PCB (A1P)
•
IPM failure
•
Current sensor failure
•
Defective of drive circuit
Troubleshooting
Refer to P.173
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
NO
YES
NO
YES
YES
NO
YES
Turn OFF the power supply
once, and turn ON again.
Does the power
supply normally come
back ON?
It is supposed that the malfunction
results from external causes other
than failures (e.g. exogenous
noises or thunder).
Check if the power
transistor is
normal.
Check if the power
transistor of the
fan driver is
normal.
Is the insulation
resistance of the
compressor 100k
Ω
and above?
Replace the
compressor and
compressor
inverter PCB
(A4P) at the same
time.
Replace the
inverter PCB
(A4P).
Replace the
compressor
inverter PCB
(A4P) and fan
inverter PCB
(A5P).
Replace the
inverter PCB
(A4P).
NO
Check 4
Check 4
CHECK 4
