Si341009 Specifications
Specifications 10
1. Specifications
1.1 Outdoor Units
Note:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name RQYQ8PY1 RQYQ10PY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 19,400 24,300
Btu / h 76,800 96,200
kW 22.5 28.2
★2 Cooling Capacity (19.0°CWB)
kW
22.4 28.0
★3 Heating Capacity
kcal / h 21,500 27,100
Btu / h 85,300 107,000
kW 25.0 31.5
Casing Colour Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1680×930×765 1680×930×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Compressor
Displacement Volume
m³/h 16.90 13.34+10.53
Number of Revolutions r.p.m 7980 6300, 2900
Motor Output×Number
of Units
kW 4.5×1 (1.4+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.75×1
Airflow Rate m³/min 180 185
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
9.5 (Brazing Connection)
φ
9.5 (Brazing Connection)
Gas Pipe mm
φ
19.1 (Brazing Connection)
φ
22.2 (Brazing Connection)
Product Mass (Machine weight) kg 230 284
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector,
Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 20~100 14~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 10.8 11.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D069102A C: 4D069103A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
