BATTERY LEVEL INDICATION
The battery is equipped with signalisation of the battery level (3
LED diodes) (14). To check battery level status, press the button
for battery level indication (13) (fig. C). When all diodes are lit,
the battery level is high. When 2 diodes are on, the battery is
partially discharged. When only one diode is lit, the battery is
discharged and must be recharged.
SPINDLE BRAKE
Drill is equipped with electronic brake that stops the spindle
immediately after the switch button (9) is released. The brake
ensures precision when screwing or drilling and prevents free
spindle rotation after switching off.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Switching on – press the switch button (9).
Switching off – release the switch button (9).
Each time the switch button (9) is pressed, the LED diode (10)
lights up to illuminate the workplace.
ROTATIONAL SPEED CONTROL
Increase or reduce pressure on the switch button (9) to adjust
rotational speed while operating. Speed control allows for soft
start, which provides working control during tightening and
undoing bolts.
CIRCUMFERENTIAL IMPACT ACTION
The tool rotates the spindle when tightening, and creates
circumferential impact. Impact action actuates automatically
when the load increases. Then a high peak torque is applied.
Keep watching the screw or bolt for full control over tightening.
Keep control over tightening force by adjusting rotational speed.
WORKING TOOL INSTALLATION
• Pull away the fixing sleeve of the tool chuck (2) (fig. D) against
the spring force.
• Insert working tool shank into the tool chuck (1) and slide it in
to mechanical stop (it may be necessary to turn the working
tool so it can reach appropriate position).
• Release the fixing sleeve of the tool chuck (2), it will finally lock
the working tool. The fixing sleeve of the tool chuck (2) will
return to its position (fig. E).
Deinstallation of the tool is similar to installation, only the
sequence of actions is reversed.
Use additional driver bit adapter with short driver bits.
RIGHT-LEFT DIRECTION OF ROTATION
Choose direction of spindle rotation with the direction selector
switch (5) (fig. F).
Clockwise rotation – set the switch (5) to the extreme left
position.
Counter-clockwise rotation – set the switch (5) to the extreme
right position.
* In certain cases position of the switch related to rotation may be different
than specified. Please refer to graphic signs located on the switch or tool
body.
Safe position of the direction selector switch (5) is in the middle,
it prevents accidental starting of the power tool.
• When the switch is in this position, the power tool cannot be
started.
• Use this position of the switch to change bits.
• Before starting the tool make sure the position of the direction
selector switch (5) is correct.
Do not change direction of rotation when the spindle of the
power tool is rotating.
Long lasting operation at low rotational speed of the
spindle may cause motor overheating. Long lasting drilling
at low rotational speed of the spindle may cause motor
overheating.
HOLDER
The power tool provides convenient holder (6) that allows to e.g.
hang the tool on a tool belt when working at heights.
OPERATION AND MAINTENANCE
MAINTENANCE AND STORAGE
• Cleaning the device after each use is recommended.
• Do not use water or any other liquid for cleaning.
• Clean the power tool, battery and charger with a dry cloth or
blow through with compressed air at low pressure.
• Do not use any cleaning agents or solvents, they may damage
plastic parts.
• Clean ventilation holes in the motor casing regularly to
prevent device overheating.
• In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a
qualified person.
• Store the power tool and its equipment in a dry place, beyond
reach of children.
• Store the device with the battery removed.
All defects should be repaired by service workshop authorized
by the manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Cordless impact driver
Parameter Value
Battery voltage 18V DC
Range of idle rotational speed 0-2200 min
-1
Tool chuck 6,35 mm (¼ ‘’)
Max. torque 180 Nm
Protection class III
Weight 1,2 kg
Year of production 2017
Graphite Energy+ System Battery
Parameter Value
Battery 58G001 58G004
Battery voltage 18 V DC 18 V DC
Battery type Li-Ion Li-Ion
Battery capacity 2000 mAh 4000 mAh
Ambient temperature range 4
0
C – 40
0
C4
0
C – 40
0
C
Charging time for charger 58G002 1 h 2 h
Weight 0,400 kg 0,650 kg
Year of production 2017 2017
