Command Line Interface Reference Manual
20
Command Purpose
description string Add description to current interface configuration
u Choose the item 9 of prompt and add the descriptions
u Please see the “Example of interface description“ to get more examples of add description of interface.
3.4.1 Set bandwidth
The information of bandwidth is use to carry out the operational decision by upper layer protocol (ULP). Use following
commands to set the bandwidth in the current interface:
Command Purpose
bandwidth kilobps Set the bandwidth for current configured interface
* Choose the item 1 of prompt and set the bandwidth
* The bandwidth is only a parameter of route that did not affect the communication rate of actual physical interface.
3.4.2 Set timing delay
The information of timing delay is used to carry out the operational decision by upper layer protocol (ULP). Following
commands set the timing delay in the current interface:
Command Purpose
delay tensofmicroseconds Set the timing delay for current configured interface
* Choose the item 8 of prompt and set the delay
The setting of timing delay is only set a parameter of information. This configuration command cannot adjust the actual
timimg delay of interface.
3.4.3 Adjust Maximum Packet Unit(MTU) Size
Each interface has a default maximum packet size or maximum transmission unit (MTU) size. This number generally
defaults to 1500 bytes. On serial interfaces, the MTU size varies, but cannot be set smaller than 68 bytes. To adjust the
maximum packet size, use the following command in interface configuration mode:
Command Purpose
Mtu bytes Set MTU for current configured interface
* Choose the item 20 of prompt and set the value of MTU
Supervise and maintain the interface
To supervise and maintain the interface by the tasks below:
Examine status of interface
D-Link Router supports the command that to display various information of interface, which is include the status of
interface and version of hardware and software. Parts of interface supervising commands are listed in the form below.
