Command Line Interface Reference Manual
21
Please see the “Command of interface configuration“ for details.
Use following commands:
Command Purpose
show interface [type slot/port] Display the status of interface
show running-config Display current configuration
show version Display setting of hardware, version of software,
filename of configuring file, source image and
boot image.
Ｔｏ ｄｉｓｐｌａｙ ｉｎｔｅｒｆａｃｅ ｓｔａｔｕｓ， ｉｎｐｕｔ ｔｈｅ ｃｏｍｍａｎｄ “ｓｈｏｗ” ｔｏ ｌｉｓｔ ａｌｌ ｔｈｅ ｐａｒａｍｅｔｅｒｓ ｉｎ ｇｌｏｂａｌ ｃｏｎｆｉｇｕｒａｔｉｏｎ
ｃｏｎｔｅｎｔｓ：
（００）ａｌｉａｓ ａｌｉａｓ ｆｏｒ ｃｏｍｍａｎｄ
......
(19)interface interface status and configuration
......
Please Input the code of command to be excute(0-45): 19
Input 19, choose the item “interface” and it will prompt:
(00)FastEthernet FastEthernet interface
(01)Ethernet Ethernet interface
(02)Serial Serial interface
(03)Async Asynchronous interface
(04)Null Null interface
Please Input the code of command to be excute(0-4): <cr>
Input the value of type, slot and port of the interface to be displayed:
To display the current configuration, input the command “show” to list all the parameters in the global configuration
contents:
(00)alias alias for command
......
(31)running-config current configuration
......
Please Input the code of command to be excute(0-45): 31
Input 31,choose the item “running-config”，it will prompt：
(00)interface interface current configuration
(01)<cr>
Please Input the code of command to be excute(0-1): 1
Input 1, it will display all the current configurations.
To display the hardware configuration, software version, name, source and boot image of the configuration documents, input the
command “show” in the global configuration contents:
(00)alias alias for command
......
(41)version router version information
......
Please Input the code of command to be excute(0-45): 41
Input 41，choose the item “version”，it will prompt：
(00)all Show all module version information
