Command Line Interface Reference Manual
41
Thus, the trap is unreliable. Oppositely, the management port of inform request receiving will adopt SNMP
responsed PDU as responsion of this message. If the management port di not receive a inform request, then the
responsion will not to be sent. If the sending port did not receive the responsion, the inform request will be resent.
Thus, the notification has more possibility that to be sent to planned destination
u The inform request occupied more resource of Router and network because it is more reliable. The trap will be
discarded as soon as it is sent. Another side, inform request must be saved in memory until the system received
responsion or request overtime. In addition, the trap can only be sent once but inform request can be sent many
times. The retransmission increased the communication traffic of network and generated more burthen. Therefore,
the trap and inform request balance the reliableility and resource. The inform request can be chose if SNMP
management port extremely need to receive each notification. If communication traffic of network or memory of
Router is more important and need not to care each notification, trap is the better choice.
u D-Link Router presently supports trap but also provides the extension of inform request.
Version of SNMP
D-Link Router presently supports following SNMP versions:
SNMPv1---Simple Network Management Protocol. A full standard of internet defined in RFC1157.
SNMPv2C--- Community based management frame of SNMPv2. Test protocol of internet that defined in RFC1901.
D-Link Router support following SNMP versions:
SNMPv3 .
SNMPv1 utilizes community based security mode to access management port that the agent of MIB. The community is
definited by IP address Access Control List and password. The agent of SNMP must be configured as the version that
supported by management workstation. The agent is able to communicate with various management ports.
Supported MIB
D-Link SNMP supports the entire MIB II variable (described at RFC 1213) and SNMP trap (described at RFC 1215).
D-Link provides private MIB extension for each system.
Creat or modify the access control for SNMP community
u The relation of SNMP management port and agent is definited by SNMP community character string. The
community character string similar as the password that allows accessing the agent of Router. The optional item
is to assign one or several features concern with community character string as below:
u Community character string is allowed to acquire the IP address access list of SNMP management port with
authority of agent access.
u To define the MIB view for the entire MIB object subset with accessing authority of assigned community.
u Assign the read/write authority of community that has the authority to access MIB object.
u Configure community character string in the mode of global configuration:
Command Function
snmp-server community string [view view-name] [ro | rw] [word] Define the community
accessing character string
Input the command “snmp-server”, it will prompt:
U(undo) D(default) Q(quit)
(00)community Enable SNMP; set community string and access privs
(01)contact Text for mib object sysContact
(02)host Specify hosts to receive SNMP TRAPs
......
Please Input the code of command to be excute(0-8): 0
Input “0”，choose the item “community”, it will prompt:
(00)WORD SNMP community string
Please Input the code of command to be excute(0-0): 0
Input 0， choose the item “WORD”, it will prompt:
Please input a string:
