Command Line Interface Reference Manual
42
Input the string，then it will prompt：
(00)WORD Std IP accesslist allowing access with this community string
(01)ro Read-only access with this community string
(02)rw Read-write access with this community string
(03)view Restrict this community to a named MIB view
(04)<cr>
Please Input the code of command to be excute(0-4):
Choose the parameter you want to configure.
One or more community can be configured. Use the command no snmp-server community to erase the given community
character string.
Please see the section "SNMP command“ to get more examples about configuration of community character string.
u Set the contact information of the route’s administrator and location of Router
sysContact and sysLocation are all management variable of system group in MIB and respectively define the operator ID
and actual location of managed node (Router). The user can access the information through the configuring file. One or
several commands below will be used in the mode of global configuration:
Command Function
snmp-server contact text Set the character string of node operator
snmp-server location text Set the character string of node location
Input the command “SNMP server”, it will prompt:
(00)community Enable SNMP; set community string and access privs
(01)contact Text for mib object sysContact
(02)host Specify hosts to receive SNMP TRAPs
(03)location Text for mib object sysLocation
......
Please Input the code of command to be excute(0-8): 1
Input “1”， choose the item “contact”, it will prompt:
(00)LINE identification of the contact person for this managed node
Please Input the code of command to be excute(0-0): 0
Input 0, choose the item “LINE”, it will prompt: Please input a string:
Input the contact string.
Input the command snmp-server, it will prompt:
(00)community Enable SNMP; set community string and access privs
(01)contact Text for mib object sysContact
(02)host Specify hosts to receive SNMP TRAPs
(03)location Text for mib object sysLocation
......
Please Input the code of command to be excute(0-8): 3
Input 3， choose the item “contact”, it will prompt:
(00)LINE identification of the contact person for this managed node
Please Input the code of command to be excute(0-0): 0
Input 0， choose the item “LINE”, it will prompt:
Please input a string:
Input the location string.
u Define the maxium length of SNMP agent data packet
The permitted maxium length of data packet can be set while SNMP agent receiving request or sending responsion. Use
