39. During slide cutting operation, the saw must be pushed and slided away
from the operator.
40. Take all the possibility of residual risks in cutting operation into your
consideration, such as the laser radiation to your eyes, the inadvertent
access to moving parts on slide mechanical parts on machine and so on.
SPECIFICATIONS
0°
65 mm × 312 mm
**75 mm × 262 mm with aux. board (30 mm)
Miter 45°
65 mm × 220 mm
**75 mm × 185 mm with aux. board (20 mm)
Left 45°
45 mm × 312 mm
**50 mm × 252 mm with aux. board (30 mm)
Bevel
Right 5°
60 mm × 312 mm
**70 mm × 252 mm with aux. board (30 mm)
Bevel (Left) 45° + Miter 45°
45 mm × 220 mm
Compound
**50 mm × 170 mm with aux. board (30 mm)
Bevel (Right) 5° + Miter 45°
60 mm × 220 mm
**70 mm × 170 mm with aux. board (30 mm)
Saw Blade Dimensions (oD × iD × Thickness) 216 mm × 30 mm × 2 mm
Miter Cutting Angle Right 0° – 57°, Left 0° – 45°
Bevel Cutting Angle Right 0° – 5°, Left 0° – 48°
Compound Cutting Angle
Bevel (Left) 0° – 45°
Miter (Right and Left) 0° – 45°
Bevel (Right) 0° – 5°
Voltage (by areas)* (110 V, 230 V)
Power Input* 1050 W
No-Load Speed 5500 min
–1
Machine Dimensions (Width × Depth × Height) 555 mm × 790 mm × 485 mm
Weight (Net) 15 kg (C8FSHE) / 14 kg (C8FSE)
Maximum output Po<3 mW Class Laser Product
(Iambda) 654 nm
Laser medium Laser Diode
Max. Cutting
Capacity
Height × Width
Laser Marker
(Only Model C8FSHE)
* Be sure to check the nameplate on product as it is subject to change by areas.
When cutting the workpiece which has the dimension of “**” there might be some possibility of the lower end of the circular saw to touch with the workpiece, even if
the motor head is located at the lower limit position. Pay attention when cutting the workpiece. For further details, refer to “PRACTICAL APPLICATIONS”. Mount the
auxiliary board on the fence surface (Refer ( ) the thickness of auxiliary board). Refer to "12. Cutting large workpieces" (Fig. 16).
STANDARD ACCESSORIES
(1) 216 mm TCT Saw blade (mounted on tool) .................................................. 1
(2) Dust bag ........................................................................................................... 1
(3) 10 mm Box wrench ......................................................................................... 1
(4) Vise Assembly ................................................................................................. 1
(5) Holder ............................................................................................................... 1
(6) Side Handle ...................................................................................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (SOLD SEPARATELY)
(1) Extension Holder and Stopper
(2) Saw blade 216 mm TCT Saw blade (Total teeth: 60)
(3) Crown molding Vise Ass'y (Include Crown molding Stopper (L))
(4) Crown molding Stopper (L)
(5) Crown molding Stopper (R)
(6) Sub Fence
Optional accessories are subject to change without notice.
APPLICATION
䡬
Cutting various types of aluminium sash and wood.
UNPACKING
䡬
Carefully unpack the power tool and all related items (standard accessories).
䡬
Check carefully to make certain all related items (standard accessories) are
present.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms to the power
requirements specified on the product nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If the plug is connected
to a receptacle while the trigger switch is in the ON position, the power tool
will start operating immediately, inviting serious accident.
