C8FSHE

Item

No.

Part Name Q’TY

1 MACHINE SCREW (W/WASHERS) M4×12 1

2 CLAMP LEVER 1

3 BOLT (LEFT HAND) D10 1

4 SPECIAL WASHER 1

5 SET PIN 1

6 O-RING (1AP-12) 1

7 MACHINE SCREW M4×85

8 BOLT WASHER M4 6

9 HINGE SHAFT (A) 1

10 SCALE (B) 1

11 LINER (A) 1

12 SPRING 1

13 TURN TABLE ASS’Y 1

14 SHAFT (B) 1

15 BOLT WASHER M12 2

16 MACHINE SCREW M4×12 1

17 INDICATOR 1

18 MACHINE SCREW M6×16 6

19 TABLE INSERT 2

20 SPACER (A) 1

21 SHAFT (A) 1

22 E-RING 1

23 SIDE HANDLE 1

24 LEVER SHAFT 1

25 LEVER 1

26 SPRING (D) 1

27 CAUTION LABEL (D) 1

28 SHAFT (C) 1

29 SEAL LOCK HEX. SOCKET SET SCREW M6×61

30 SPRING (E) 1

31 STOPPER (A) 1

32 COVER (B) 1

33 THRUST WASHER 1

34 PIN COVER 1

35 KNOB BOLT M10×66 1

36 WING BOLT M6×15 1

37 SCREW HOLDER 1

38 BOLT WASHER M6 1

39 VISE SHAFT 1

40 VISE PLATE 1

41 MACHINE SCREW M4×10 1

42 VISE ASS’Y 1

43 BOLT M8×35 4

44 SPRING WASHER M8 4

45 BOLT WASHER M8 4

46 WING BOLT M6×17 1

47 FENCE (B) 1

52 HOLDER 1

53 BOLT M6×10 1

54 LINER 3

55 FENCE (A) 1

56 BASE ASS’Y 1

57 BASE RUBBER 4

58 SCALE (A) 1

59 CAUTION LABEL (A) 1

81 MACHINE SCREW 2

82 BOLT WASHER M4 6

83 COVER 1

84 SLEEVE 1

85 SPRING 1

Item

No.

Part Name Q’TY

86 SEAL LOCK HEX. SOCKET SET. SCREW M8×10 4

87 HINGE (A) ASS’Y 1

88 ADJUSTER 1

89 MACHINE SCREW M5×12 1

90 SPACE 1

91 LINK 1

92 HINGE SHAFT (A) 1

93 BASE RUBBER 1

94 O-RING (P-6) 1

95 STOPPER PIN ASS’Y 1

96 CLUTCH SCREW 1

97 CLUTCH SPRING 1

98 ADJUSTING WASHER (B) T0.5 1

99 PLATE (B) 1

100 SPRING 1

101 CLUTCH SPRING 1

102 SPRING 2

103 SEAL LOCK HEX. SOCKET SET SCREW M5×62

104 COVER (A) 1

105 PLATE (A) 1

106 HOLDER (B) 1

107 LASER MARKET 1

108 MACHINE SCREW M4×12 3

109 CAUTION LABEL (J) 1

110 CORD 1

111 MACHINE SCREW (W/WASHERS) M4×12 1

112 NYLON CLIP 1

113 SUPPORT 1

114 BALL BUSHING 1

115 BUSHINGH 1

116 KNOB BOLT M6×25 1

117 LOCK SPRING 1

118 SEAL LOCK HEX. SOCKET SET SCREW M6×10 1

119 MACHINE SCREW M4×12 1

120 INDICATOR 1

121 SEAL LOCK HEX. SOCKET SET SCREW M6×82

122 TAPPING SCREW (W/FLABGE) D5×25 1

123 NYLOCK BOLT (A) M8×25 2

124 HOLDER (A) 1

125 GUARD ASS’Y 1

151 TAPPING SCREW (W/FLANGE) D4×16 3

152 CORD ARMOR D10.1 1

153 CORD CLIP 1

154 CORD BUSH 1

155 HOUSING ASS’Y 1

156 NAME PLATE 1

157 MACHINE SCREW (W/WASHERS) M5×40 3

158 HEX. SOCKET SET SCREW M5×82

159 BRUSH HOLDER 2

160 CARBON BRUSH 2

161 BRUSH CAP 2

162 TAPPING SCREW (CLASS 2) D4×14 1

163 TAPPING SCREW (W/FLANGE) D4×20 7

164 HANDLE COVER 1

165 SWITCHING POWER SUPPLY 1

166 FERRITE CORE 1

167 SWITCH (W/COVER) 2

169 INTERNAL WIRE (G) 1

170 SWITCH 1

171 PILLAR TERMINAL (A) 1
