DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

Figure 4-38 Multicast Static FDB Settings window

The fields that can be configured are described below:

Parameter Description

VID

The VLAN ID of the VLAN the corresponding MAC address belongs to.

Multicast MAC Address

The static destination MAC address of the multicast packets. This must be a multicast

MAC address.

Port

Allows the selection of ports that will be members of the static multicast group and

ports that are either forbidden from joining dynamically, or that can join the multicast

group dynamically, using GMRP. The options are:

None - No restrictions on the port dynamically joining the multicast group. When None

is chosen, the port will not be a member of the Static Multicast Group. Click the All

button to select all the ports.

Egress - The port is a static member of the multicast group. Click the All button to

select all the ports.

Click the Clear All button to clear out all the information entered.

Click the Apply button to accept the changes made.

MAC Notification Settings

MAC Notification is used to monitor MAC addresses learned and entered into the forwarding database. This window

allows you to globally set MAC notification on the Switch. Users can set MAC notification for individual ports on the

Switch.

To view the following window, click L2 Features > FDB > MAC Notification Settings as shown below:
