DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

315

Parameter Description

TFTP Server IP

Enter the TFTP server IP address used.

IPv4

Click the radio button to enter the TFTP server IP address used.

IPv6

Click the radio button to enter the TFTP server IPv6 address used.

Domain Name

Click the radio button to enter the TFTP server domain name used.

Destination File

Enter the file name that will be stored in the TFTP server, e.g. log.log.

Log Type

Select the type of log to be transferred. Selecting the Common Log option here will upload

the common log entries. Selecting the Attack Log option here will upload the log

concerning attacks.

Click Upload to initiate the upload.

Upload Log To FTP

This window is used to upload the log file from the Switch to a FTP Server.

Figure 12-17 Upload Log – FTP window

The fields that can be configured are described below:

Parameter Description

FTP Server IP

Enter the FTP Server IP Address used.

User Name

Enter the appropriate Username used.

Password

Enter the appropriate Password used.

TCP Port

Enter the TCP Port number used.

Destination File

Enter the file name that will be stored in the FTP server, e.g. log.log.

Log Type

Select the type of log to be transferred. Click Common Log to upload the common log

entries. Click Attack Log to upload the log concerning attacks.

Click Upload to initiate the upload.

Upload Log To HTTP

This window is used to upload the log file from the Switch to a computer.
