DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide
199
Figure 8-15 Authenticator Statistics window
The fields that can be configured are described below:
Parameter Description
Time Interval
Use the drop-down menu to select the interval to update the statistics.
Click the OK button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings window
before initializing ports. Information in this window cannot be viewed before enabling the authentication
mode for either Port-based or MAC-based.
Authenticator Session Statistics
This window is used to display the authenticator session statistics information.
To view this window, click Security > 802.1X > Authenticator Session Statistics as shown below:
