Successful login using any of these techniques will give the user a "User" privilege only. If the user wishes to upgrade

his or her status to the administrator level, the user must use the Enable Admin window, in which the user must enter

a previously configured password, set by the administrator.

To view this window, click Security > Access Authentication Control > Login Method Lists Settings as shown

below:

Figure 8-62 Login Method Lists Settings window

The Switch contains one Method List that is set and cannot be removed, yet can be modified. To delete a Login

Method List defined by the user, click the Delete button corresponding to the entry desired to be deleted. To modify a

The fields that can be configured are described below:

Parameter Description

Method List Name

Enter a method list name defined by the user of up to 15 characters.

Priority 1, 2, 3, 4

The user may add one, or a combination of up to four of the following authentication

methods to this method list:

tacacs - Adding this parameter will require the user to be authenticated using the

TACACS protocol from a remote TACACS server.

xtacacs - Adding this parameter will require the user to be authenticated using the

XTACACS protocol from a remote XTACACS server.

tacacs+ - Adding this parameter will require the user to be authenticated using the

TACACS+ protocol from a remote TACACS+ server.

radius - Adding this parameter will require the user to be authenticated using the

RADIUS protocol from a remote RADIUS server.

local - Adding this parameter will require the user to be authenticated using the local

user account database on the Switch.

none - Adding this parameter will require no authentication needed to access the

Switch.

Click the Apply button to accept the changes made.

Click the Edit button to re-configure the specific entry.

Click the Delete button to remove the specific entry.

Enable Method Lists Settings

Users can set up Method Lists to promote users with user level privileges to Administrator (Admin) level privileges

using authentication methods on the Switch. Once a user acquires normal user level privileges on the Switch, he or

she must be authenticated by a method on the Switch to gain administrator privileges on the Switch, which is defined

by the Administrator. A maximum of eight Enable Method Lists can be implemented on the Switch, one of which is a

default Enable Method List. This default Enable Method List cannot be deleted but can be configured.

The sequence of methods implemented in this command will affect the authentication result. For example, if a user

enters a sequence of methods like TACACS - XTACACS - Local Enable, the Switch will send an authentication

request to the first TACACS host in the server group. If no verification is found, the Switch will send an authentication

request to the second TACACS host in the server group and so on, until the list is exhausted. At that point, the Switch
