DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

Figure 2-12 Port Error Disabled

The fields that can be displayed are described below:

Parameter Description

Port

Display the port that has been error disabled.

Port State

Describe the current running state of the port, whether enabled or disabled.

Connection Status

Display the uplink status of the individual ports, whether enabled or disabled.

Reason

Describe the reason why the port has been error-disabled, such as it has become a

shutdown port for storm control.

Port Media Type

The following window displays the information about the port media type.

To view the following window, click System Configuration > Port Configuration > Port Media Type, as shown

below:

Figure 2-13 Port Media Type window

Jumbo Frame Settings

The Switch supports jumbo frames. Jumbo frames are Ethernet frames with more than 1,536 bytes of payload. The

Switch supports jumbo frames with a maximum frame size of up to 9,216 bytes.

To view the following window, click System Configuration > Port Configuration > Jumbo Frame Settings as

shown below:
