D-Link DGS-1510-28XMP/ME [243/342] Access authentication control

DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

234

The fields that can be configured are described below:

Parameter Description

Server IP Address

The IP address of the DHCP server to be permitted.

Client’s MAC Address

Enter the MAC address of the client.

Ports

The port numbers of the filter DHCP server. Tick the All Ports check box to include

all the ports on this switch for this configuration.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specific entry.

Access Authentication Control

The TACACS / XTACACS / TACACS+ / RADIUS commands allow users to secure access to the Switch using the

TACACS / XTACACS / TACACS+ / RADIUS protocols. When a user logs in to the Switch or tries to access the

administrator level privilege, he or she is prompted for a password. If TACACS / XTACACS / TACACS+ / RADIUS

authentication is enabled on the Switch, it will contact a TACACS / XTACACS / TACACS+ / RADIUS server to verify

the user. If the user is verified, he or she is granted access to the Switch.

There are currently three versions of the TACACS security protocol, each a separate entity. The Switch's software

supports the following versions of TACACS:

1 TACACS (Terminal Access Controller Access Control System) - Provides password checking and

authentication, and notification of user actions for security purposes utilizing via one or more centralized

TACACS servers, utilizing the UDP protocol for packet transmission.

2 Extended TACACS (XTACACS) - An extension of the TACACS protocol with the ability to provide more

types of authentication requests and more types of response codes than TACACS. This protocol also uses

UDP to transmit packets.

3 TACACS+ (Terminal Access Controller Access Control System plus) - Provides detailed access control

for authentication for network devices. TACACS+ is facilitated through Authentication commands via one or

more centralized servers. The TACACS+ protocol encrypts all traffic between the Switch and the TACACS+

daemon, using the TCP protocol to ensure reliable delivery

In order for the TACACS / XTACACS / TACACS+ / RADIUS security function to work properly, a TACACS /

XTACACS / TACACS+ / RADIUS server must be configured on a device other than the Switch, called an

Authentication Server Host and it must include usernames and passwords for authentication. When the user is

prompted by the Switch to enter usernames and passwords for authentication, the Switch contacts the TACACS /

XTACACS / TACACS+ / RADIUS server to verify, and the server will respond with one of three messages:

The server verifies the username and password, and the user is granted normal user privileges on the Switch.

The server will not accept the username and password and the user is denied access to the Switch.

The server doesn't respond to the verification query. At this point, the Switch receives the timeout from the server and

then moves to the next method of verification configured in the method list.

The Switch has four built-in Authentication Server Groups, one for each of the TACACS, XTACACS, TACACS+ and

RADIUS protocols. These built-in Authentication Server Groups are used to authenticate users trying to access the

Switch. The users will set Authentication Server Hosts in a preferable order in the built-in Authentication Server

Groups and when a user tries to gain access to the Switch, the Switch will ask the first Authentication Server Hosts for

authentication. If no authentication is made, the second server host in the list will be queried, and so on. The built-in

Authentication Server Groups can only have hosts that are running the specified protocol. For example, the TACACS

Authentication Server Groups can only have TACACS Authentication Server Hosts.

The administrator for the Switch may set up six different authentication techniques per user-defined method list

(TACACS / XTACACS / TACACS+ / RADIUS / local / none) for authentication. These techniques will be listed in an

order preferable, and defined by the user for normal user authentication on the Switch, and may contain up to eight

authentication techniques. When a user attempts to access the Switch, the Switch will select the first technique listed

for authentication. If the first technique goes through its Authentication Server Hosts and no authentication is returned,
