DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide
327
9: dot3OamEventLogValue
10: dot3OamEventLogRunningTotal
11: dot3OamEventLogEventTotal
swPowerFailure 1: swPowerUnitIndex
2: swPowerID
3: swPowerStatus
V2 EQUIPMENT-MIB
(Equipment.mib)
swPowerRecover 1: swPowerUnitIndex
2: swPowerID
3: swPowerStatus
V2 EQUIPMENT-MIB
(Equipment.mib)
swFanFailure 1: swFanUnitIndex
2: swFanID
V2 EQUIPMENT-MIB
(Equipment.mib)
swFanRecover 1: swFanUnitIndex
2: swFanID
V2 EQUIPMENT-MIB
(Equipment.mib)
swHighTemperature 1: swTemperatureUnitIndex
2: swTemperatureCurrent
V2 EQUIPMENT-MIB
(Equipment.mib)
swHighTemperatureRecover 1: swTemperatureUnitIndex
2: swTemperatureCurrent
V2 EQUIPMENT-MIB
(Equipment.mib)
swLowTemperature 1: swTemperatureUnitIndex
2: swTemperatureCurrent
V2 EQUIPMENT-MIB
(Equipment.mib)
swLowTemperatureRecover 1: swTemperatureUnitIndex
2: swTemperatureCurrent
V2 EQUIPMENT-MIB
(Equipment.mib)
swPktStormOccurred swPktStormCtrlPortIndex V2 PKT-STORM-CTRL-MIB
(PktStormCtrl.mib)
swPktStormCleared swPktStormCtrlPortIndex V2 PKT-STORM-CTRL-MIB
(PktStormCtrl.mib)
swSafeGuardChgToExhausted swSafeGuardCurrentStatus V2 SAFEGUARD-ENGINE-MIB
(SafeGuard.mib)
swSafeGuardChgToNormal swSafeGuardCurrentStatus V2 SAFEGUARD-ENGINE-MIB
(SafeGuard.mib)
swIpMacBindingViolationTrap 1: swIpMacBindingPortIndex
2: swIpMacBindingViolationIP
3: swIpMacBindingViolationMac
V2 IP-MAC-BIND-MIB
(IPMacBind.mib)
swMacBasedAccessControlLoggedSuc
cess
1: swMacBasedAuthInfoMacIndex
2: swMacBasedAuthInfoPortIndex
3: swMacBasedAuthVID
V2 Mac-Based-Authentication-MIB
(mba.mib)
swMacBasedAccessControlLoggedFail 1: swMacBasedAuthInfoMacIndex
2: swMacBasedAuthInfoPortIndex
3: swMacBasedAuthVID
V2 Mac-Based-Authentication-MIB
(mba.mib)
swMacBasedAccessControlAgesOut 1: swMacBasedAuthInfoMacIndex
2: swMacBasedAuthInfoPortIndex
3: swMacBasedAuthVID
V2 Mac-Based-Authentication-MIB
(mba.mib)
swFilterDetectedTrap 1: swFilterDetectedIP
2: swFilterDetectedport
V2 FILTER-MIB (Filter.mib)
swPortLoopOccurred swLoopDetectPortIndex V2 LOOPBACK-DETECT-MIB
(LBD.mib)
swPortLoopRestart swLoopDetectPortIndex V2 LOOPBACK-DETECT-MIB
(LBD.mib)
swVlanLoopOccurred swLoopDetectPortIndex V2 LOOPBACK-DETECT-MIB
(LBD.mib)
swVlanLoopRestart 1: swLoopDetectPortIndex
2: swVlanLoopDetectVID
V2 LOOPBACK-DETECT-MIB
(LBD.mib)
swDdmAlarmTrap 1: swDdmPort
2: swDdmThresholdType
3: swDdmThresholdExceedType
V2 DDM-MGMT-MIB (DDM.mib)
swDdmWarningTrap 1: swDdmPort
2: swDdmThresholdType
V2 DDM-MGMT-MIB (DDM.mib)
