DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

224

Compound Authentication Guest VLAN Settings

Users can assign ports to or remove ports from a guest VLAN.

To view this window, click Security > Compound Authentication > Compound Authentication Guest VLAN

Settings as shown below:

Figure 8-43 Compound Authentication Guest VLAN Settings window

The fields that can be configured are described below:

Parameter Description

VLAN Name

Click the button and assign a VLAN as a Guest VLAN. The VLAN must be an existing

static VLAN.

VID (1-4094)

Click the button and assign a VLAN ID for a Guest VLAN. The VLAN must be an

existing static VLAN before this VID can be configured.

Port List

The list of ports to be configured. Alternatively, tick the All Ports check box to set every

port at once.

Action

Use the drop-down menu to choose the desired operation: Create VLAN, Add Ports, or

Delete Ports.

Click the Apply button to accept the changes made.

Click the Delete button to remove the specific entry.

Port Security

Port Security Settings

A given port’s (or a range of ports') dynamic MAC address learning can be locked such that the current source MAC

addresses entered into the MAC address forwarding table cannot be changed once the port lock is enabled. The port

can be locked by changing the Admin State drop-down menu to Enabled and clicking Apply.

Port Security is a security feature that prevents unauthorized computers (with source MAC addresses) unknown to the

Switch prior to locking the port (or ports) from connecting to the Switch's locked ports and gaining access to the

network.

To view this window, click Security > Port Security > Port Security Settings as shown below:
