DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

To view the following window, click System Configuration > PoE > PoE System Settings as shown below:

Figure 2-16 PoE System Settings window

The following parameters can be configured:

Parameter Description

Power Limit

Sets the limit of power to be used from the Switch’s power source to PoE ports. The user

may configure a Power Limit between 37W and 193W for DGS-1510-28LP/ME, and

between 37W and 370W for DGS-1510-28XMP/ME.

Power Disconnect

Method

The PoE controller uses either Deny Next Port or Deny Low Priority Port to offset the power

limit being exceeded and keeps the Switch’s power at a usable level. Use the drop down

menu to select a Power Disconnect Method. The default Power Disconnect Method is

Deny Next Port. Both Power Disconnection Methods are described below:

Deny Next Port – After the power limit has been exceeded, the next port attempting to

power up is denied, regardless of its priority. If Power Disconnection Method is set to Deny

Next Port, the system cannot utilize out of its maximum power capacity. The maximum

unused watt is 10W for DGS-1510-28LP/ME and 19W for DGS-1510-28XMP/ME.

Deny Low Priority Port – After the power limit has been exceeded, the next port attempting

to power up causes the port with the lowest priority to shut down so as to allow the high-

priority and critical priority ports to power up.

Legacy PD

Use the drop-down menu to enable or disable detecting legacy PDs signal.

Click Apply to implement changes made.

PoE Port Settings

To view the following window, click System Configuration > PoE > PoE Port Settings as shown below:
