DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

95

MAC Address Aging

Time (10-1000000)

This field specify the length of time a learned MAC Address will remain in the

forwarding table without being accessed (that is, how long a learned MAC Address is

allowed to remain idle). To change this option, type in a different value representing

the MAC address’ age-out time in seconds. The MAC Address Aging Time can be

This allows the Switch's MAC address forwarding table to be viewed. When the Switch learns an association between

a MAC address, VLAN and a port number, it makes an entry into its forwarding table. These entries are then used to

forward packets through the Switch.

To view the following window, click L2 Features > FDB > MAC Address Table as shown below:

Figure 4-41 MAC Address Table window

The fields that can be configured are described below:

Parameter Description

Click the Find button to locate a specific entry based on the information entered.

Click the Clear Dynamic Entries button to delete all dynamic entries of the address table.

Click the View All Entries button to display all the existing entries.

Click the Clear All Entries button to remove all the entries listed in the table.

Click the Add to Static MAC table button to add the specific entry to the Static MAC table.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

On this page the user can find the ARP and FDB table parameters.
