DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

Figure 2-4 DDM Temperature Threshold Settings window

The fields that can be configured are described below:

Parameter Description

From Port / To Port

Select a range of ports to be configured.

High Alarm (-128-

127.996)

This is the highest threshold for the alarm. When the operating parameter rises above this

value, action associated with the alarm will be taken.

Low Alarm (-128-

127.996)

This is the lowest threshold for the alarm. When the operating parameter falls below this

value, action associated with the alarm will be taken.

High Warning (-128-

127.996)

This is the highest threshold for the warning. When the operating parameter rises above

this value, action associated with the warning will be taken.

Low Warning (-128-

127.996)

This is the lowest threshold for the warning. When the operating parameter falls below this

value, action associated with the warning will be taken.

Click the Apply button to accept the changes made.

DDM Voltage Threshold Settings

This window is used to configure the DDM Voltage Threshold Settings for specific ports on the Switch.

To view the following window, click System Configuration > Port Configuration > DDM > DDM Voltage Threshold

Settings as shown below:
