DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide
325
successful.
<ipaddr | ipv6address>, MAC: <macaddr>, Port:
<portNum>)
When a client host fail to
authenticate.
WAC unauthenticated user (User Name: <string>, IP:
<ipaddr | ipv6address>, MAC: <macaddr>, Port:
<portNum>)
Warning
This log will be triggered when the
number of authorized users
reaches the maximum user limit
on the whole device.
WAC enters stop learning state Warning
This log will be trigge
red when the
number of authorized users is
below the maximum user limit on
whole device in a time interval
(The interval is project
dependent).
WAC recovered from stop learning state Warning
Y.1731 AIS condition detected AIS condition detected. MD Level: <mdlevel>, VLAN:
<vlanid>, Local (Port <portNum>, Direction:
<mepdirection>, MEPID: <mepid>)
Notice
AIS condition cleared AIS condition cleared. MD Level: <mdlevel>, VLAN:
<vlanid>, Local (Port <portNum>, Direction:
<mepdirection>, MEPID: <mepid>)
Notice
LCK condition detected LCK condition detected. MD Level: <mdlevel>, VLAN:
<vlanid>, Local (Port <portNum>, Direction:
<mepdirection>, MEPID: <mepid>)
Notice
LCK condition cleared LCK condition cleared. MD Level: <mdlevel>, VLAN:
<vlanid>, Local (Port <portNum>, Direction:
<mepdirection>, MEPID: <mepid>)
Notice
DHCPv6 Client DHCPv6 client interface
administrator state changed
DHCPv6 client on interface <intf-name> changed state
to <enabled | disabled>
Informational
DHCPv6 client obtains an ipv6
address from a DHCPv6 server
DHCPv6 client obtains an ipv6 address <ipv6address>
on interface <intf-name>
Informational
The IPv6 address obtained from a
DHCPv6 server starts renewing
The IPv6 address <ipv6address> on interface <intf-
name> starts renewing
Informational
The IPv6 address obtained from a
DHCPv6 server renews success
The IPv6 address <ipv6address> on interface <intf-
name> renews success
Informational
The IPv6 address obtained from a
DHCPv6 server starts rebinding
The IPv6 address <ipv6address> on interface <intf-
name> starts rebinding
Informational
The IPv6 address obtained from a
DHCPv6 server rebinds success
The IPv6 address <ipv6address> on interface <intf-
name> rebinds success
Informational
The IPv6 address was deleted The IPv6 address <ipv6address> on interface <intf-
name> was deleted
Informational
Voice VLAN When a new voice device is
detected in the port
New voice device detected (Port <portNum>, MAC
<macaddr>)
Informational
When a port which is in auto
Voice VLAN mode joins the Voice
VLAN
Port <portNum> add into voice VLAN <vid> Informational
When a port leaves the Voice
VLAN and at the same time, no
voice device is detected in the
aging interval for that port, the log
message will be sent
Port <portNum> remove from voice VLAN <vid> Informational
