DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide
329
swCFMExtLockOccurred 1: dot1agCfmMdIndex
2: dot1agCfmMaIndex
3: dot1agCfmMepIdentifier
V2 CFMEXTENSION-MIB
(CFMExtension.MIB)
swCFMExtLockCleared 1: dot1agCfmMdIndex
2: dot1agCfmMaIndex
3: dot1agCfmMepIdentifier
V2 CFMEXTENSION-MIB
(CFMExtension.MIB)
