DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

201

Figure 8-17 Authenticator Diagnostics window

The fields that can be configured are described below:

Parameter Description

Time Interval

Use the drop-down menu to select the interval to update the statistics.

Click the OK button to accept the changes made.

NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings window

before initializing ports. Information in this window cannot be viewed before enabling the authentication

mode for either Port-based or MAC-based.

Initialize Port-based Port(s)

This window is used to display the authenticator diagnostics information.

To view this window, click Security > 802.1X > Initialize Port-based Port(s) as shown below:

Figure 8-18 Initialize Port-based Port(s) window

The fields that can be configured are described below:

Parameter Description
