DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

Chapter 3 Management

ARP

Gratuitous ARP

IPv6 Neighbor Settings

IP Interface

Management Settings

Session Table

Single IP Management

SNMP Settings

Telnet Settings

Web Settings

ARP

Static ARP Settings

The Address Resolution Protocol is a TCP/IP protocol that converts IP addresses into physical addresses. This table

allows network managers to view, define, modify, and delete ARP information for specific devices. Static entries can

be defined in the ARP table. When static entries are defined, a permanent entry is entered and is used to translate IP

addresses to MAC addresses.

To view the following window, click Management > ARP > Static ARP Settings as shown below:

Figure 3-1 Static ARP Settings window

The fields that can be configured are described below:

Parameter Description

ARP Aging Time (0-65535)

The ARP entry age-out time, in minutes. The default is 20 minutes.

IP Address

The IP address of the ARP entry.

MAC Address

The MAC address of the ARP entry.

Click the Apply button to accept the changes made for each individual section.

Click the Delete All button to remove all the entries listed.

Click the Edit button to re-configure the specific entry.

Click the Delete button to remove the specific entry.

ARP Table

Users can display current ARP entries on the Switch.

To view the following window, click Management > ARP > ARP Table as shown below:
