DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

System Log Server Settings

The Switch can send System log messages to up to four designated servers using the System Log Server.

To view the following window, click System Configuration > System Log Configuration > System Log Server

Settings as shown below:

Figure 2-21 System Log Server Settings

The fields that can be configured are described below:

Parameter Description

Server ID

Syslog server settings index (1 to 4).

Severity

Use the drop-down menu to select the higher level of messages that will be sent. All

messages which level is higher than selecting level will be sent. The options are

Emergency, Alert, Critical, Error, Warning, Notice, Informational and Debug.

Server IPv4 Address

The IPv4 address of the Syslog server.

Facility

Use the drop-down menu to select Local 0, Local 1, Local 2, Local 3, Local 4, Local 5,

Local 6, or Local 7.

UDP Port (514 or

6000-65535)

Type the UDP port number used for sending Syslog messages. The default is 514.

Status

Choose Enabled or Disabled to activate or deactivate.

Click the Apply button to accept the changes made.

Click the Edit button to re-configure the specific entry.

Click the Delete button to remove the specific entry.

Click the Delete All button to remove all servers configured.

System Log

Users can view and delete the local history log as compiled by the Switch's management agent.

To view the following window, click System Configuration > System Log Configuration > System Log as shown

below:

Figure 2-22 System Log window
