DGS-1510/ME Series Metro Ethernet Switch Web UI Reference Guide

Figure 2-8 DDM RX Power Threshold Settings window

The fields that can be configured are described below:

Parameter Description

From Port / To Port

Select a range of ports to be configured.

High Alarm (0-

6.5535)

This is the highest threshold for the alarm. When the operating parameter rises above this

value, action associated with the alarm will be taken.

Low Alarm (0-

6.5535)

This is the lowest threshold for the alarm. When the operating parameter falls below this

value, action associated with the alarm will be taken.

High Warning (0-

6.5535)

This is the highest threshold for the warning. When the operating parameter rises above

this value, action associated with the warning will be taken.

Low Warning (0-

6.5535)

This is the lowest threshold for the warning. When the operating parameter falls below this

value, action associated with the warning will be taken.

Click the Apply button to accept the changes made.

DDM Status Table

This window is used to display the current operating digital diagnostic monitoring parameters and their values on the

SFP module for specified ports.

To view the following window, click System Configuration > Port Configuration > DDM > DDM Status Table as

shown below:
