Functional Description ESIE-0302
2–14 Part 2 – Functional Description
3
1
2
4
5
Control settings The table below contains the settings for head pressure control.
(1)
: The factory setting for high-pressure is 16 bar with a 4 bar pressure difference.
Unit If high-pressure is... Fan speed is...
5 HP
(1)
>= 16 bar Maximum speed
= 12 bar Minimum speed
< 12 bar 0 (fan motor stops)
16 bar > high-pressure > 12 bar Fan speed control
8-10 HP >= 22 bar High speed
< 12 bar Low speed
