Malfunction Indications and Safeties Overview ESIE-0302
3–12 Part 3 – Troubleshooting
3
1
3
4
5
2.3 Malfunction Indications Overview: EUWA*5-24KZW1 and EUWY*5-24KZW1
Alarm and warning
codes
The following alarm and warning codes may appear on the screen:
What happens in
the event of an
alarm or a warning
In the event of an alarm or a warning, the following happens:
Code Description
Alarm or
warning
Reset See page
a1 The anti-freeze alarm has been activated. Alarm Manual 2–36
d1 The unit is carrying out a defrost cycle (only for EUWY5-24KZW1). Warning Automatic
e1 NTC probe used to measure the inlet water temperature is defective. Alarm Automatic 3–18
e2 NTC probe used to measure the outlet water temperature is defective. Alarm Automatic 3–18
e3 The fuse for evaporator heater tape is blown or there is a reverse
phase error or there is a problem with the I/O PCB (A2P).
Alarm Automatic
ee/ep EEPROM on the digital controller inside the unit is defective. Alarm Automatic 1–90
fl No water flow for:
■ 15 s after the pump was started, or
■ 5 s while the compressor is active.
Alarm Manual 2–34
h1 The high-pressure switch, the discharge thermal protection or the over-
current protection of the compressor motor is activated or NTC probe
to measure the ambient temperature is defective.
Alarm Manual —
l1 The low-pressure switch is activated. Alarm Manual —
n1 The compressor requires maintenance. The total running hours of the
compressor (direct parameter c9) has exceeded the setting of the
timer threshold for maintenance warning (user parameter cb —see
"How to access the parameters" on page 2–37).
Warning Manual 3–11
n2 The compressor requires maintenance. The total running hours of the
compressor (direct parameter ca) has exceeded the setting of the
timer threshold for maintenance warning (user parameter cb —see
"How to access the parameters" on page 2–37).
Warning Manual 3–11
r1 The period foreseen for defrost has elapsed but the process of
defrosting is not completed (only for EUWY5-24KZW1).
Warning Manual
e0 Voltage is too high. Alarm Automatic —
ei Voltage is too low. Alarm Automatic —
el Noise of power supply Alarm Automatic —
vn Error in the communication with the remote terminal. Alarm Automatic —
Alarm Warning
■ The unit is shut down.
■ The buzzer is activated.
■ The alarm relay is energized.
■ The display starts flashing, alternately showing the
alarm code(s) and the inlet water temperature.
The display starts flashing, alternately
showing the warning code and the inlet
water temperature.
