Checking the Inputs and Outputs ESIE-0302
3–20 Part 3 – Troubleshooting
3
1
3
4
5
3.4 I/O PCB sensors: R3T and R4T for EUWA*5-24KZW1 and EUWY*5-24KZW1
Temp.-resistance The table below contains the temperature resistance values of the I/O PCB sensors R3T and R4T.
Temp.
(°C)
Resistance (k:)
Temp.
(°C)
Resistance (k:)
Temp.
(°C)
Resistance (k:)
Maximum Standard Minimum Maximum Standard Minimum Maximum Standard Minimum
-50 344.40 329.20 314.70 4 23.42 22.99 22.57 58 3.28 3.21 3.14
-49 324.70 310.70 297.20 5 22.45 22.05 21.66 59 3.18 3.11 3.04
-48 306.40 293.30 280.70 6 21.52 21.15 20.78
60 3.09 3.02 2.95
-47 289.20 277.00 265.30 7 20.64 20.29 19.95 61 2.99 2.92 2.86
-46 273.20 261.80 250.60 8 19.80 19.40 19.15 62 2.90 2.83 2.77
-45 258.10 247.50 237.20 9 19.00 18.70 18.40 63 2.81 2.75 2.69
-44 244.00 234.10 224.60
10 18.24 17.96 17.67 64 2.73 2.66 2.60
-43 230.80 221.60 212.70 11 17.51 17.24 16.97 65 2.65 2.58 2.52
-42 218.50 209.80 201.50 12 16.80 16.55 16.31 66 2.57 2.51 2.45
-41 206.80 198.70 191.00 13 16.13 15.90 15.87 67 2.49 2.43 2.37
-40 195.90 188.40 181.10 14 15.50 15.28 15.06 68 2.42 2.36 2.30
-39 185.40 178.30 171.59 15 14.89 14.68 14.48 69 2.35 2.29 2.24
-38 175.5. 168.90 162.00 16 14.31 14.12 13.93
70 2.28 2.22 2.17
-37 166.20 160.10 154.10 17 13.75 13.57 13.40 71 2.21 2.16 2.10
-36 157.50 151.80 140.20 18 13.22 13.06 12.89 72 2.15 2.10 2.04
-35 149.30 144.00 138.80 19 12.72 12.56 12.41 73 2.09 2.04 1.98
-34 141.60 136.60 131.80
20 12.23 12.09 11.95 74 2.03 1.98 1.93
-33 134.40 129.70 125.20 21 11.77 11.63 11.07 75 1.97 1.92 1.87
-32 127.60 123.20 118.90 22 11.32 11.20 11.07 76 1.92 1.87 1.82
-31 121.20 117.10 113.10 23 10.90 10.78 10.60 77 1.86 1.81 1.78
-30 115.10 111.30 107.50 24 10.49 10.38 10.27 78 1.81 1.76 1.71
-29 109.30 105.70 102.20 25 10.10 10.00 9.90 79 1.76 1.71 1.68
-28 103.80 100.40 97.16 26 9.73 9.63 9.52
80 1.71 1.66 1.62
-27 98.63 95.47 92.41 27 9.38 9.28 9.18 81 1.66 1.62 1.57
-26 93.75 90.80 87.93 28 9.04 8.94 8.84 82 1.62 1.57 1.53
-25 89.15 86.39 83.70 29 8.72 8.62 8.52 83 1.57 1.53 1.49
-24 84.82 82.22 79.71
30 8.41 8.31 8.21 84 1.53 1.49 1.44
-23 80.72 78.29 75.93 31 8.11 8.01 7.91 85 1.49 1.45 1.40
-22 76.85 74.58 72.36 32 7.82 7.72 7.62 86 1.45 1.41 1.37
-21 73.20 71.07 68.99 33 7.55 7.45 7.35 87 1.41 1.37 1.33
-20 69.74 67.74 65.80 34 7.28 7.19 7.09 88 1.37 1.33 1.29
-19 66.42 64.54 62.72 35 7.03 6.94 6.84 89 1.34 1.30 1.26
-18 63.27 61.52 59.81 36 6.79 6.69 6.60
90 1.30 1.26 1.22
-17 60.30 58.66 57.05 37 6.56 6.46 6.37 91 1.27 1.23 1.19
-16 57.49 55.95 54.44 38 6.33 6.24 6.15 92 1.23 1.20 1.16
-15 54.83 53.39 51.97 39 6.12 6.03 5.94 93 1.20 1.16 1.13
-14 52.31 50.96 49.83
40 5.92 5.82 5.73 94 1.17 1.13 1.10
-13 49.93 48.66 47.12 41 5.72 5.63 5.54 95 1.14 1.10 1.07
-12 47.67 46.48 45.31 42 5.53 5.43 5.35 96 1.11 1.08 1.04
-11 45.53 44.41 43.32 43 5.34 5.25 5.17 97 1.08 1.05 1.01
-10 43.50 42.25 41.43 44 5.16 5.08 4.99 98 1.05 1.02 0.99
-9 41.54 40.56 39.59 45 4.99 4.91 4.82 99 1.03 0.99 0.96
-8 39.68 38.76 37.85 46 4.83 4.74 4.66
100 1.00 0.97 0.94
-7 37.91 37.05 36.20 47 4.67 4.59 4.51 101 0.98 0.94 0.91
-6 36.24 35.43 34.03 48 4.52 4.44 4.36 102 0.95 0.92 0.89
-5 34.65 33.89 33.14 49 4.38 4.30 4.22 103 0.93 0.90 0.87
-4 33.14 32.43 31.73
50 4.24 4.16 4.08 104 0.91 0.87 0.84
-3 31.71 31.04 30.39 51 4.10 4.02 3.95 105 0.88 0.85 0.82
-2 30.35 29.72 29.11 52 3.97 3.90 3.82 106 0.86 0.83 0.80
-1 20.00 28.47 27.89 53 3.84 3.77 3.69 107 0.84 0.81 0.78
0 27.83 27.28 26.74 54 3.72 3.65 3.57 108 0.82 0.79 0.76
1 26.64 26.13 25.62 55 3.61 3.53 3.46 109 0.80 0.77 0.74
2 25.51 25.03 24.55 56 3.49 3.42 3.35
110 0.78 0.75 0.73
3 24.24 23.99 23.54 57 3.39 3.31 3.24 —
