General Outline ESIE-0302
1–48 Part 1 – System Outline
3
1
1
4
5
1.19 Electrical Specifications: EUWY*16-20KZW1
Electrical
specifications
The table below contains the electrical specifications.
Model EUWYN16KZW1 EUWYP16KZW1 EUWYB16KZW1 EUWYN20KZW1 EUWYP20KZW1 EUWYB20KZW1
Power supply
Phase 3N~
Frequency 50 Hz
Voltage 400 V
Voltage tolerance ± 10 %
Unit
Starting current 97.9 A 99.9 A 113 A 115 A
Nominal running
current cooling
27.2 A 29.2 A 31.8 A 33.8 A
Max. running
current
33.8 A 35.8 A 39.8 A 41.8 A
Recommended
fuses
3 x 40 gL/gG 3 x 50 gL/gG 3 x 50 gL/gG 3 x 50 gL/gG
Fans
Phase 1~
Voltage 230 V
Max. running
current
5.8 A
Compressor
Phase 3~
Voltage 400 V
Starting current 95.0 A 110.0 A
Nom. running
current cooling
10.7 A 13.0 A
Max. running
current
14.0 A 17.0 A
Starting method Direct on line
Control circuit
Phase 1~
Voltage 230 V
Recommended
fuses
Factory installed
Pump
Phase__3~__3~
Voltage __ 400.0 V __ 400.0 V
Max. running
current
__ 2.0 A __ 2.0 A
