ESIE-0302 Checking the Inputs and Outputs
Part 3 – Troubleshooting 3–23
33
4
5
1
3.7 Checking the Power Supply and Fuses: EUWAC5-10FZW1
Overview The table below contains an overview of the circuits, the voltage and their fuse codes.
Overview fuses and
overcurrent
The table below contains the used fuses and overcurrent.
Recommended fuses according to IEC standard 269-2: gL/gG (aM also admitted)
(F1U, F2U, F3U = gL/gG)
Circuit Wiring code Type / voltage Fuse code
Main supply L1 + L2 + L3 + N 3 phases / 400 V AC F1U+F2U+F3U
Control circuit (fans + relay) for
EUWAC5FZ
L1 + N 1 phase / 230 V AC F7B
Control circuit (fans + relay) for
EUWAC8-10FZ
L1 + L2 + L3 + N 3 phases / 400 V AC F7B
Control circuit (PCBs) TR1-prim. 1 phase / 230 V AC F5B
TR1-sec. 24 V AC F9B
Fuses + overcurrent EUWAC5FZW1 EUWAC8FZW1 EUWAC10FZW1
F1U, F2U, F3U 25gG 32gG 32gG
F5B 1A 1A 1A
F7B 10A 6A 6A
F9B 1A 1A 1A
F8U 315 mAT 315 mAT 315 mAT
F9U 125 mAT 125 mAT 125 mAT
K4S 11A 18A 21A
