Inputs and Outputs Overview ESIE-0302
3–4 Part 3 – Troubleshooting
3
1
3
4
5
1.2 Inputs and Outputs Overview: EUWAC5-10FZW1
Inputs/outputs The table below describes the relation between the wiring diagram symbols, the wiring connections
and the error codes.
For the exact location, see "Wiring Diagram: EUWAC5-10FZW1" on page 1–101.
Type Device
Wiring
diagram
symbol
Wiring con-
nection
terminal
Error code Description
Analog
input
Sensor R3T X1/B1-GND e1 - a1 Inlet water temperature sensor
R4T X1/B2-GND e2 (r6) Outlet water temperature sensor
Digital input Trans-
ducer
R1P X1/ALL h1 / fl Reverse phase protector
S11L+S10L X1/ID1-GND h1 Flow switch + pump contact
S4LP X1/ID4-GND l1 Low-pressure switch
K4S + K1A
+ QID
X1/ID3-GND c1 / h1 Overcurrent relay + auxiliary relay for high
pressure + discharge protector
Control
contacts
S9S (field) X1/ID5-GND (h7) Switch for remote start/stop
S10L (field) X1/ID1-GND (fl) Flow switch
S11L (field) 75-77 — Contact that closes if the pump is working
Digital out-
put
— K1M X2C1/2-NO1 — Compressor contactor
KP (field) X2C3/4-NO3 — Pump contactor
H1P (field) X2C5-NO5 — Indication lamp alarm
