Daikin EUWAC5FZW [145/264] Start stop
![Daikin EUWAC5FZW [145/264] Start stop](/views2/1657184/page145/bg91.png)
The Digital Controller ESIE-0302
2–34 Part 2 – Functional Description
3
1
2
4
5
2.3 Start/Stop
At power ON When the power is ON, the display shows the inlet water temperature.
Start/stop
■ Press c for 5 s to start or stop in cooling mode.
■ Press h for 5 s to start or stop in heating mode (only for heat pump).
Remote start/stop,
remote cool/heat
The procedure to start or stop the unit depends on the setting of the remote start/stop. See "Start/Stop"
on page 2–34.
The procedure to cool or heat (only for EUWY5-24KZW1) depends on the setting of the remote
cool/heat. See "Settings: Direct and User Parameters" on page 2–37.
Start/stop and
cool/heat selection
for
EUWY*5-24KZW1
The table below contains information on how to select start or stop or how to select cooling or heating
mode.
Setting the
temperature
Use the
u and d keys to adjust the water temperature.
If start/stop
set-up is...
and cool/heat
set-up is...
, then... to...
Local (h7=0) Local (h6=0)
Press
c for 5 s
Start/stop in cooling mode.
Always stop the unit before
you switch to cooling because
start/stop and cool/heat are
combined in the same button.
Press
h for 5 s
Start/stop in heating mode.
Always stop the unit before
you switch to cooling because
start/stop and cool/heat are
combined in the same button.
Remote (h7=1) Local (h6=0)
Press
c for 5 s
Cool.
Press
h for 5 s
Heat.
Switch remote start/stop Start/stop.
Remote (h7=1) Remote (h6=1) Switch remote start/stop Start/stop.
Switch remote cool/heat Cool/heat.
Local (h7=0) Remote (h6=1) Switch remote cool/heat Switch on the unit
automatically .
Only cool/heat selection is
possible.
