ESIE-0302 Troubleshooting
Part 3 – Troubleshooting 3–29
33
4
5
1
Part 3
4 Troubleshooting
4.1 What Is in This Chapter?
Introduction When a problem occurs, you have to check all possible malfunctions.
This chapter gives a general idea of where to look for malfunctions. Furthermore, the general
procedures for refrigeration circuit and electrical circuit repair are described.
Not all repair procedures are described. Some procedures are considered common practice.
Overview This chapter contains the following topics:
Topic See page
4.2–Items to Be Checked 3–30
4.3–General Repair Procedures 3–32
4.4–Unlocking the Keyboard 3–33
4.5–Replacing the Controller: EUWAC5-10FZW1 3–34
4.6–Replacing the Controller: EUWA*5-24KZW1 3–39
4.7–Replacing the Controller: EUWY*5-24KZW1 3–44
4.8–Replacing the PCB: EUWA*5-24KZW1 and EUWY*5-24KZW1 3–50
4.9–Soft Starter (option EKSS) Thermal Protection 3–51
