Pre-Test Run Checks ESIE-0302
4–4 Part 4 – Commissioning and Test Run
3
1
4
5
1.2 General Checks
Checklist The table below contains the general checklist.
Step Check whether...
1 There is external damage.
2 The unit is properly supported and/or has a proper foundation.
3 The unit is installed horizontally with a deviation of maximum 1˚.
4 Anti-vibration pads are required.
5 Is the chiller of the type EUWY*5-24KZW1?
■ When yes, go to step 6.
■ When no, go to step 8.
6 There is a drain possibility for condensed water.
7 A heater tape is placed inside the drain system. This is necessary to prevent ice accumu-
lation and possible blockage during wintertime.
8 Is the chiller of the type EUWAC5-10FZW1?
■ When yes, go to step 9.
■ When no, check for remaining metal dust of burrs. Metal dust or burrs from grinding or
drilling in the metal construction parts during construction facilitates the rust process
and shortens the unit’s lifetime.
9 The operator has received the operation manual.
10 The installer has received the installation manual.
11 The air volume over the coil is adequate; there is no blockage (from paper, plastic...) or air
short circuit due to wrong positioning.
